Description
Constructed from iron, the Spira Brass Adjustable Field Gate Kit is configured as a fully adjustable double-strap hinge set for 3″ heavy-duty field, drive and entrance gates.
Its adjustable arrangement allows the installer to establish the gate position during fitting and make subsequent corrections if the gate drops over time. The hook-to-bolt component incorporates a hole for a security pin, intended to help prevent removal of the gate. Finish options comprise Galvanised Zinc and Black Powder Coated, both specified for resistance to corrosion.
Key Facts:
- Brand: Spira Brass
- Material: Iron
- Format: Adjustable field gate kit
- Hinge arrangement: Double strap
- Fully adjustable
- Allows adjustment during and after installation
- Designed to compensate for gate drop over time
- Suitable for 3″ heavy-duty field gates
- Also suitable for 3″ heavy-duty drive and entrance gates
- Hook-to-bolt component includes a security-pin hole
- Security-pin provision intended to prevent gate removal
- Finishes: Galvanised Zinc, Black Powder Coated
- Corrosion-resistant finish specification
Fit or Compatibility Note:
Confirm the 3″ gate requirement, hinge fixing locations and adjustment arrangement before specification. The product information identifies a hole for a security pin but does not confirm that the pin itself is supplied.
Dimensions
12″ Kit:
Top Strap Length (Straps only): 250mm
Top Strap Length (Including Pin Hole, i.e Total Length): 305mm
Bottom Strap Length (Straps only): 135mm
Bottom Strap Length (Including Pin Hole, i.e Total Length): 190mm
Suitable for Gate length: 3 Feet (0.915m) – 4 Feet (1.22m) Long Gates
Hook To Bolt Diameter: 19mm
Hook to Bolt Total Length: 280mm
Hook to Bolt length (Excluding Pin): 235mm
Hook To Drive Diameter: 19mm
Hook to Drive Length: 205mm
Hook to Drive length (Excluding Pin): 165mm
18″ Kit:
Top Strap Length (Straps only): 395mm
Top Strap Length (Including Pin Hole, i.e Total Length): 450mm
Bottom Strap Length (Straps only): 135mm
Bottom Strap Length (Including Pin Hole, i.e Total Length): 190mm
Suitable for Gate Length: 5 Feet (1.525m) – 7 Feet (2.13m) Long Gates
Hook To Bolt Diameter: 19mm
Hook to Bolt Total Length: 280mm
Hook to Bolt length (Excluding Pin): 235mm
Hook To Drive Diameter: 19mm
Hook to Drive Length: 205mm
Hook to Drive length (Excluding Pin): 165mm
24″ Kit:
Top Strap Length (Straps only): 550mm
Top Strap Length (Including Pin Hole, i.e Total Length): 605mm
Bottom Strap Length (Straps only): 135mm
Bottom Strap Length (Including Pin Hole, i.e Total Length): 190mm
Suitable for Gate Length: 8 Feet (2.44m) – 14 Feet (4.27m) Long Gates
Hook To Bolt Diameter: 19mm
Hook to Bolt Total Length: 280mm
Hook to Bolt length (Excluding Pin): 235mm
Hook To Drive Diameter: 19mm
Hook to Drive Length: 205mm
Hook to Drive length (Excluding Pin): 165mm
