Description
This Eclipse ball bearing hinge is manufactured from mild steel and specified to Grade 13 for compatible doors with a maximum total mass of 120kg. Its documented performance includes 200,000-cycle testing under BS EN 1935, BS EN 1634 fire testing and CE and UKCA credentials.
Key Facts:
- Manufacturer: Eclipse
- Ball bearing hinge construction
- Material: Mild steel
- Size: 102x76mm
- Thickness: Source information conflicts between 2.7mm and .7mm – verification required
- Grade: 13
- Maximum total door mass: 120kg
- BS EN 1935 tested to 200,000 cycles
- Fire tested to BS EN 1634
- Stated fire performance: FD30, 60-minute timber door
- Certification: CE, UKCA
- 10 gauge countersunk
- Fixings: 10x1.1/2" Pozi Drive screws with 3/4" threaded section
- Pack options: 2 pieces, 3 pieces
Fit or Compatibility Note:
Review the hinge size, door mass and fixing positions before specification. Where fire performance is required, consider the hinge in relation to the complete tested door assembly.
